Prouduct Description
| Electrical Characteristics | Nominal Voltage | 12.8v |
| Nominal Capacity | 12Ah | |
| Energy | 153.6Wh | |
| Maximum Modules In Series | 1 | |
| Cycle Life | >3000 cycles @ 1C 100% DOD | |
| Months Self Discharge | <3% | |
| Effciency of Charge | 100%@0.5C | |
| Effciency of Discharge | 96-99%@1C | |
| Standard Charge | Charge Cut-off Voltage | 14.6±0.1V |
| Charge Mode | 0.2C to 14.6V,then 14.6V,charge current to 0.02C(CC/CV) | |
| Standard Charge current | 6A | |
| Max charge current | 12A | |
| Standard Discharge | Standard Continuous current | 12A |
| Max pulse current | 24A(<5s) | |
| Discharge Cut-off Voltage | 10V | |
| Environmental | Charge Temperature | 0 ºC to 45 ºC @60±25% Relative Humidity |
| Discharging Temperature | -20 ºC to 60 ºC @60±25% Relative Humidity | |
| Storage Temperature | 0 ºC to 40 ºC @60±25% Relative Humidity | |
| Mechanical Specifications | Plastic Case | ABS plastic shell |
| Dimension | 380 x 180 x 235mm | |
| Terminal | T2 | |
| Weight | 1.8kg | |
| Enclosure Protection | IP56 | |
| Package | 6pcs/Ctn, 360pcs/Tray, 3600pcs/20GP |
Features of LiFePO4 Battery
1,Longer Cycle Life:Offers up to 20times longer life and five times longer fioat life than lead acid battery, helping to minimize
replacement cost and reduce total cost of ownership.
2,Lighter Weight:About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.
3,Higher Power:Delivers twice power of lead acid battery,even high discharging rate,while maintaining high energy capacity.
4,wider Temperature Range:-20ºC-60ºC.
5,Superior Safety:Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact,
overcharging or short circuit situation.
6,Increased Flexibility:Modular design enables deployment of up to four batteries in series and up to batteries in parallel.
